Amprobe AM-120 TRMS Multimeter Digital PC Connection

Name: Amprobe AM-120 TRMS Multimeter Digital PC Connection
Brand: Amprobe
SKU: AmprobeAM-120TRMS
Price: 103.25 USD
Availability: InStock

0 reviews | UPC: 0 95969 36597 0 | Model: Amprobe AM-120TRMS

Compare

DIGITAL MULTIMETER, TRMS, W/ PC CONNECTION

True TRMS
Optical isolated PC interface capability
Auto and manual ranging
Auto power off
Data hold
Backlight display
Large, easy to read LCD display
Auto compensation of the test leads resistance
Diode test
Audible continuity
Limited Life Time Warranty

View Product Details

List Price: $139.95

In Stock:

View Payment Options

Recommended for you

Technical
AC Voltage	50.00/500.0mV, 5.000/50.00/500.0/1000V ±(0.5% Rdg + 3 LSD) @ 50 and 60Hz
DC Voltage	50.00/500.0mV, 50.00/500.0mV ±(0.08% Rdg + 2 LSD) @ 5V to 1000V ranges
Resistance	50.00/500.0? 5.000/50.00/500.0k? 5.000/50.00M? ±(0.2% Rdg + 6 LSD) @ 50? to 500k? ranges
AC/DC Currrent	500.0/5000μA, 50.00/500.0mA, 5.000/10.00A DC: ±(0.2% Rdg + 4 LSD)
AC	±(1.0% Rdg + 4 LSD)
Frequency	6Hz to 125 kHz for all setups except: 6Hz to 1kHz for 500V and 1000V ranges 6Hz to 20kHz for 50V range ±(0.01% Rdg + 2 LSD)
Capacitance	50.00/500.0nF, 5.000/50.00/500.0/9999μF ±(2.0% Rdg + 3 LSD) @ 50nF to 50μF ranges
Temperature	-58°F to 1832°F (-50°C to 1000°C) ±(0.3% Rdg + 3 LSD)
Data recording	N/A
Relative Zero mode	N/A
UPC/DCI	11962
Safety	CAT III 600V
