| Technical |
| AC/DC Voltage |
1.6 - 599.9V ±(1% Rdg + 3 LSD) |
| AC Peak Voltage @ 1ms response time |
10 - 850V ±(5% Rdg + 10 LSD) |
| AC Current |
0 - 399.9V ±(1% Rdg + 3 LSD) |
| AC Peak Current @ 1ms response time |
10 - 800A ±(5% Rdg + 10 LSD) |
| Resistance |
0 ? 499.9/999/1999? ±(1% Rdg + 5 LSD) |
| Frequency (with test leads and jaw) |
40.0 - 399.9Hz ±(0.5% Rdg + 1 LSD) |
| Active, Reactive and Apparent Power |
0.00 ? 99.99/999.9 kW, kVAR, kVA ±(3.5% Rdg + 3 LSD) |
| Power Factor, Cos Ø |
0.20 - 1.00 ±(2% Rdg + 2 LSD) |
| Safety Standards |
| Comply with |
EN 61010 |
| Insulation |
Class 2, double reinforced insulation |
| Pollution |
Level 2 |
| For inside use, max height |
2000m |
| Over voltage |
CAT III 600V between terminals and ground |
| Mechanical Characteristics |
| Size |
205(L) x 64 (W) x 39(D)mm |
| Weight (including battery) |
about 280g |
| Jaws opening |
30mm |
| Max conductor size |
30mm |
| Power Supply |
| Battery type |
2 batteries 1.5V AAA. |
| Low battery indication |
Symbol "" is displayed when battery level is too low. |
| Battery life |
About 90 hours of continued measurement |
| Display Characteristics |
4 dgt LCD with maximum reading 9999 units plu decimal point and sign. |
| Sample rate |
64 samples in 20ms |
| Conversion mode |
TRMS |
| Environmental Conditions |
| Reference temperature |
23° ± 5°C |
| Operating temperature |
5 - 40 °C |
| Operating humidity |
<80% RH |
| Storage temperature |
-10 - 60 °C |
| Storage humidity |
<80% RH |
| EMC |
This apparatus was designed in accordance with EMC standards in force and its compatibility has been tested in accordance EN61326 (1997) + A1 (1998) + A2 (2001). This product conforms to the prescriptions of the European directive on low voltage 73/23/EEC (LVD) and to EMC directive 89/336/EEC, amended by 93/68/EEC. |
| Accessories |
| The accessories contained inside the packaging are the following |
Instrument, Rubber holster (MTL-CAP), Test leads (MTL-90B), Carrying Case (SV-U), User?s manual |
