| General Specifications |
| Built-in digital camera |
• |
| Infrared heat map overlay |
Five blending modes: 0%, 25%, 50%, 75%, 100% |
| Color palettes |
Grey Scale, Hot Iron, Rainbow |
| Field of view |
33 ° x 33 ° |
| Focus system |
Focus free |
| IR temperature range |
14 °F to 932 °F (-10 °C to 500 °C) |
| Distance to Spot ratio (D:S) |
20:1 |
| Emissivity |
0.10 to 1.00 |
| Display resolution |
0.2 °F/0.1 °C |
| Hot and cold markers |
• |
| Center point marker |
• |
| Temperature units |
Selectable °F/°C |
| Memory storage |
• |
| Laser sighting |
• |
| Flashlight |
• |
| UV light |
• |
| Auto power off |
• |
| UV light |
5 blue LEDs |
| Flash light |
4 LEDs |
| Laser sighting |
Circle/dot/center point laser, Output < 1 mW, wavelength 650 nm |
| Temperature measurement |
Yes, center point |
| Temperature range |
14 °F to 932 °F (-10 °C to 500 °C) |
| IR accuracy (calibration geometry with ambient temperature 23°C ± 2°C) |
≥ 32 °F (≥ 0 °C): ± 4 °F (± 2 °C) or ± 2 % of the reading, whichever is greater |
| Display resolution |
0.2 °F / 0.1 °C |
| IR Repeatability |
± 0.8 % of the reading or ± 2 °F (± 1 °C), whichever is greater |
| Temperature Coefficient |
0.1 °C/°C or ± 0.1 %/°C of the reading, whichever is greater |
| Distance to spot |
20:1 |
| Minimum spot size |
0.32 in (8 mm) |
| Response time (95 %) |
< 125 ms |
| Spectral response |
8 μm to 14 μm |
| Emissivity |
Digitally adjustable from 0.10 to 1.00 by 0.01 |
| Visual image with infrared heat map overlay |
Five blending modes (0%, 25%, 50%, 75% and 100%) |
| Visual image resolution |
16,384 pixels (128 x 128 pixels) (Interpolation pixels) |
| IR detector resolution |
32 x 32 pixels |
| Field of view |
33 ° x 33 ° |
| Thermal sensitivity |
150 mK |
| Focus system |
Focus free |
| Image palettes |
Grey Scale (white hot), Hot Iron and Rainbow |
| Hot and cold marker |
Yes |
| Center point marker |
Yes |
| Display |
1.77 in color TFT with 128 x 160 pixels |
| Data storage |
Stored image size: 124 x 160 pixels, Image file size: typical 40 KB, Estimated stored images on a 2 G SD card: approx. 50,000 |
| Operating temperature and humidity |
32 °F to 122 °F (0 °C to 50 °C), 10 % to 90 % RH non-condensing at 86 °F (30 °C) |
| Storage temperature |
-4 °F to 140 °F (-20 °C to 60 °C) without batteries |
| Visual to IR effective image alignment |
≥ 10 in (25.4 cm), Optimal for 1 m |
| Laser sighting to center of visual image |
≥ 18 in (45 cm) typical |
| Laser pointer to center of UV field |
Approx. 18 in (45 cm) typical |
| Operating and storage altitude |
< 6561 ft (< 2000 m) |
| Drop proof |
4 ft (1.2 m) |
| Vibration and shock |
IEC 60068-2-6, 2.5g, 10 to 200 Hz, IEC 60068-2-27, 50g 11ms |
| Power supply |
Three (3) 1.5 V AA IEC LR6 alkaline batteries |
| Battery life |
8 hours with display ON (Typical) Power consumption: 150 mA (Typical) |
| Auto power off |
Selectable modes: OFF, 1 minute, 2 minutes, 5 minutes and 10 minutes |
| Laser safety compliance |
EC 60825-1, Class 2 |
| Electromagnetic compatibility |
Korea (KCC): Class A Equipment (Industrial Broadcasting & Communication Equipment) [1] [1] This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and is not to be used in homes |
| Size (H x W x L) |
Approx. 7.3 x 2.1 x 4.1 in (185 x 54 x 104 mm) |
| Weight |
Approx. 0.64 lb (0.29 kg) |
