Display: 3 ¾ digit liquid crystal display (LCD)(3999 count) with a 41-segment analog bar-graph. Polarity: Automatic, positive implied, negative polarity indication. Overrange: (o) or (-o) is displayed. Zero: Automatic. Low battery indication: The B is displayed when the battery voltage drops below the operating level. Auto power off: Approximately 30 minutes. Measurement rate: 2 times per second, nominal. Operating environment: 0 °C to 50 °C at 70 % R.H. Storage temperature: -20 °C to 60 °C, 0 to 80 % R.H. with battery removed from meter. Temperature Coefficient: 0.1 ?? (specified accuracy) per °C. (0 °C to 18 °C, 28 °C to 50 °C). Environment: Indoor use, altitude up to 2000 m Power: Single standard 9-volt battery, NEDA 1604, JIS 006P, IEC 6F22. Battery life: 150 hours typical with carbon-zinc. 300 hours typical with alkaline. Dimensions: 196 mm (H) x 92 mm (W) x 60 mm (D). Weight: Approximately 400 g including battery. Warranty: One-Year Battery Life: 300 hrs typical (alkaline) Size: 7.7" x 3.5" x 2.3" (196 x 92 x 60 mm) Safety: Cat II 1000V, Cat III 600V DC Voltage Ranges: 400 mV, 4 V, 40 V, 400 V, 1000 V DC Voltage Accuracy: all ranges: ± (0.7 % rdg + 1 dgt) DC Voltage Resolution: 100 µV DC Voltage Input Impedance: 10 M? AC Voltage (45 Hz to 500 Hz) Ranges: 400 mV, 4 V, 40 V, 400 V, 750 V AC Voltage (45 Hz to 500 Hz) Accuracy: 4 V Range, 200 Hz to 500 Hz: ± (2.0 % rdg + 4 dgts) AC Voltage (45 Hz to 500 Hz) Accuracy: All other ranges: ± (1.5 % rdg + 4 dgts) AC Voltage (45 Hz to 500 Hz) Resolution: 100 µV AC Voltage (45 Hz to 500 Hz) Input Impedance: 10 M? DC Current Ranges: 400 µA, 4 mA, 40 mA, 300 mA, 10 A DC Current Accuracy: 400 µA to 300 mA ranges: ± (1.0 % rdg + 1 dgt) DC Current Accuracy: 10 A range: ± (2.0 % rdg + 3 dgts) DC Current Resolution: 0.1 µA DC Current Voltage Burden: 400 µA range: 1 mV/µA, 4 mA range: 100 mV/1 mA, 40 mA range: 12 mV/1 mA, DC Current Voltage Burden: 300 mA range: 4 mV/1 mA, 10 A range: 100 mV/1 A AC Current (45 Hz to 500 Hz) Ranges: 400 µA, 4 mA, 40 mA, 300 mA, 10 A AC Current (45 Hz to 500 Hz) Accuracy: 400 µA to 300 mA ranges: ± (1.5 % rdg + 4 dgts) AC Current (45 Hz to 500 Hz) Accuracy: 10 A range: ± (2.5 % rdg + 4 dgts) AC Current (45 Hz to 500 Hz) Resolution: 0.1 µA AC Current (45 Hz to 500 Hz) Voltage Burden: See DC Current Resistance Ranges: 400 ? 40 k? 4 M? Resistance Accuracy: 400 ?and 40 k? ranges: ± (1.0 % rdg + 4 dgts) Resistance Accuracy: 4 M? range: ± (1.2 % rdg + 4 dgts) Resistance Resolution: 100 m? Resistance Open Circuit Voltage: 400 ? range: 3.0 V dc, All other ranges: 0.5 V dc typical Ranges: 4 kHz, 40 kHz, 400 kHz, 4 MHz, 40 MHz Accuracy: all ranges: ± (0.1 % rdg + 3 dgts) Resolution: 1 Hz Sensitivity: 10 Hz to 4 MHz: 1.5 V ac rms 4 MHz to 40 MHz: 2 V ac rms, 5 V ac rms Min Pulse Width: 25 ns Duty Cycle Limits: 30 % and 70 % Audible Indication: 35 ? Response Time: 100 ms Test Current: 1.0 mA (approximate) Accuracy: ± (1.5 % rdg + 3 dgts) Resolution: 1 mV Open Circuit Volts: 3.0 V dc typical AC Volts Accuracy: 40 V to 750 V: ± (3.0 % rdg + 60 dgts) AC Current Accuracy: ± (3.0 % rdg + 60 dgts) Response Time: 1 ms AC/DC Voltage: 400 mV range: 1000 V dc or 750 V ac rms 15 sec All other ranges: 1000 V dc or 750 V ac rms AC/DC Current: uA/mA input: 0.315 A /1000 V fast-blow ceramic (6.3 x 32 mm) 10 A input: 10 A /1000 V fast-blow ceramic (10 x 38 mm) (10 A for 4 minutes maximum followed by a 12 minute cooling period) Resistance: 1000 V dc or 750 V ac rms Continuity: 1000 V dc or 750 V ac rms Diode Test: 1000 V dc or 750 V ac rms Capacitance: 0.315 A /1000 V fast-blow ceramic (6.3 x 32 mm) Temperature: 1000 V dc or 750 V ac rms Frequency: 1000 V dc or 750 V ac rms |
