Allied Moulded AMP1082CCF PLYLIN 10X8X2 PC ENCL CLEAR SCR COV FLNG

Name: Allied Moulded AMP1082CCF PLYLIN 10X8X2 PC ENCL CLEAR SCR COV FLNG
Brand: Allied Moulded
SKU: AlliedAMP1082CCF
Price: 53.15 USD
Availability: InStock

0 reviews | UPC: 085339973928 | Model: Allied Moulded AMP1082CCF

Compare

PLYLIN 10X8X2 PC ENCL CLEAR SCR COV FLNG

Nonmetal flange fastened to back side brass inserts
Cover Type: Clear Polycarbonate
Closure Type: 4-screw lift-off
Non-corrosive
Non-conductive
Light weight with lower installation cost
Easy to modify and longer life cycle compared to steel
Rigid design with back panel inserts plus nonmetallic mounting brackets and a gasket system encased in a continuous channel on the cover

View Product Details

List Price: $64.93

Your Price: $53.15

In Stock:

View Payment Options

Request Quote

Items in This Series



Product	Allied Moulded AMP1082CCF PLYLIN 10X8X2 PC ENCL CLEAR SCR COV FLNG	Allied Moulded AMP1082LF PLYLIN 10X8X2 PC ENCL HNG SL CVR FLNG	Allied Moulded AMP1082L PLYLIN 10X8X2 PC ENCL HNG SL CVR FLNG	Allied Moulded AMP1082HF PLYLIN 10X8X2 PC ENCL HNG SCR CVR FLNG	Allied Moulded AMP1082H PLYLIN 10X8X2 PC ENCL HNG SCR CVR FEET	Allied Moulded AMP1082F PLYLIN 10X8X2 PC ENCL HNG SCR CVR FEET	Allied Moulded AMP1082CCLF PLYLIN 10X8X2 PC ENCL HNG SCR CVR FEET	Allied Moulded AMP1082CCL PLYLIN 10X8X2 PC ENCL HNG SCR CVR FEET	Allied Moulded AMP1082CCHF PLYLIN 10X8X2 PC ENCL CLEAR HNG SCR CVR FLNG	Allied Moulded AMP1082CCH PLYLIN 10X8X2 PC ENCL CLEAR HNG SCR CVR FEET	Allied Moulded AMP1082CC PLYLIN 10X8X2 PC ENCL CLEAR SCR COV FLNG	Allied Moulded AMP1082 PLYLIN 10X8X2 PC ENCL SCR COV FEET
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Allied Moulded AMP Series Polycarbonate Wall Mount Enclosure

Nonmetal flange fastened to back side brass inserts

Non-conductive
Light weight with lower installation cost
Easy to modify and longer life cycle compared to steel

The AMP polycarbonate series was developed primarily for general purpose industrial applications as an alternative to steel enclosures. The design of this product group is similar to the ULTRALINE® series and includes a provision for adjustable HFP (hinged front panel) position. Additional POLYLINE® options include a clear cover, nonmetallic snap latches, and patented multi-mounting capabilities. Available sizes include 6" x 6" x 4" (152mm x 152mm x 102mm) up through 18" x 16" x 10" (457mm x 406mm x 254mm).

Application

Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.

General Specifications
Enclosure Type	JIC Size
Cover Type	Clear Polycarbonate
Closure Type	4-screw lift-off
Mounting Description	Nonmetal flange fastened to back side brass inserts
Height	9.93 in
Width	8.15 in
Depth	2.7 in
Usable Depth	2.68 in
Volume	290 cu. in.
Brand	POLYLINE®
UPC	85339973928
UNSPSC	39121324
Carton Quantity	1
Carton Weight	3 lbs
Country of Origin	United States of America
Color	Gray (RAL 7035) with clear cover
Patents	U.S. Patent No. 7,572,975
Material	Polycarbonate box and clear polycarbonate cover
Additional Materials	316 stainless steel external hardware (hinges/latches/fasteners), Polycarbonate mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
