Input |
1x ICP® powered accelerometer |
Input range: |
60g PEAK with standard 100mV/g sensor
(e.g.600g PEAK for 10mV/g sensor, the sensitivity is editable
in the unit) |
Measurements |
Velocity RMS 10 - 1 000 Hz [mm/s, ips]
Velocity Peak 10 - 1 000 Hz [mm/s, ips]
Acceleration RMS 500 - 16 000 Hz [g]
Acceleration Peak 500 - 16 000 Hz [g]
Velocity time 1 - 1 000 Hz [mm/s, ips] 2048 samples *
Velocity spectrum 1 - 1 000 Hz [mm/s, ips] 800 lines
Acceleration time 1 - 16 000 Hz [g] 2048 samples *
Acceleration spectrum 1 - 16 000 Hz [g] 800 lines *
Acceleration Demod-Envelope RMS 500 - 16 000 Hz [g]
Acceleration Demod-Envelope Peak 500 - 16 000 Hz [g] *
Acceleration Demod-Envelope time 500 - 16 000 Hz [g]
2048 samples
Acceleration Demod-Envelope spectrum 500 - 16 000 Hz [g]
800 lines, range 400 Hz *
Displacement RMS 2 - 100 Hz [µm, mil]
Displacement 0 - Peak 2 - 100 Hz [µm, mil]
Displacement Peak - Peak 2 - 100 Hz [µm, mil]
Temperature non-contact measurement 0 - 380°C (32 - 716°F) |
Further functions |
LED stroboscope (0,17 - 300 Hz, 10 - 18 000 RPM)
LED torch,
non-contact temperature measurement
vibration stethoscope |
Memory |
4 MB for data
900 measurements of 800 lines spectra or 2048 samples time
signals may be stored |
Data storing (option) |
Off-Route
Route with DDS 2014 software for Vibrio M
(free download) |
Interface |
USB 2.0 compatible |
Software |
DDS 2014 software for Vibrio M (free download) |
Display |
colour graphic OLED display 128 x 128 pixels,
diagonal 1,5“ (38mm) |
Output |
1x AC signal 8 Ω / 0,5 W for external headphones
(signal listening) |
Power |
2x AA 1.5V batteries (alkaline, NiMH, Lithium - 8 hours
operation) |
Temp |
Operating: -5°C to 55°C |
Dimensions |
150 x 60 x 35 mm |
Weight |
330 g including batteries (without cable, sensor
and magnet)
540 g including batteries, cable, sensor and magnet |
Accessories |
vibration sensor, coiled cable to connect vibration
sensor, magnetic base for vibration sensor, headphones
with 3.5 mm jack, USB cable, measuring tip for manual
pressure on the sensor, transport case, CD with the
manual |
