Aaronia OFG 30100E - Omnidirectional RF Test Signal Transmitter (30MHz - 1GHz)

0 reviews | Catalog: AR 372 | Model: Aaronia OFG 30100E


OFG 30100E - Omnifield Generator

  • Omnidirectional RF Test Signal Transmitter
  • Frequency range: 30 MHz to 1GHz
  • Frequency accuracy: 1Hz (<600MHz), 20Hz (>600MHz)
  • Modulations: AM, FM, PM
  • Combination of Signal Generator and biconical Antenna
  • Up to 3V/m output power (0,5m distance)
  • Combination of biconical antenna and signal generator
  • Perfect for RF immunity measurements
  • Perfect for RF attenuation measurements
  • Highest power level: +18dBm
  • Smallest power level: -45dBm
  • Up to 63dB dynamic range
  • Onboard TCXO for very high frequency accuracy
  • Can be connected to external reference clock for even higher accuracy (female SMA-connector)
  • Onboard CPU and memory for intelligent self-running profiles
  • Stand alone operation (no PC or USB connection required)
  • Battery operation up to 4h
  • USB connector for realtime PC control or for storing programs
  • Incl. 12V power supply for continuous operation
  • Can be operated from 12V Car and Truck power system
  • Dimensions: 540x225x225mm
  • Small Weight, 3lbs with battery
View Product Details

List Price: $3,102.30
