AFL 8700-06-0002MR - Encircled Flux Modal Conditioner, 62.5/125 µm, FC/FC

Technology improvements continue to push the envelope on multimode fiber optic networks. Ever increasing bandwidth requires tighter specifications (lower loss connectors, splices, Etc.). Shrinking loss budgets in turn place higher demands on loss test sets for accurate and repeatable measurements.

Encircled Flux (EF) testing requirements attempt to improve loss test set performance by placing defined parameters on optical test signals emitted from multimode loss test sources. AFL Mode Controller Jumpers (MCJs) are simple to use while ensuring the output test signal conforms to EF specifications regardless of the multimode test source used.

Simple-to-use

Plug MCJ input into an LED multimode test source and you have an EF compliant output meeting TIA-568-14-B and IEC 621180-4-1.

Several versions available
