AEMC 2110.75 - AC Current Probe Model MD314

Name: AEMC 2110.75 - AC Current Probe Model MD314
Brand: AEMC Instruments
SKU: AEMC2110.75
Price: 141.55 USD
Availability: InStock

0 reviews | UPC: 068533807006 | Model: AEMC Instruments 2110.75

Compare

AC Current Probe Model MD314 (500A, 1mV/A, Lead)

Unique hook-shaped jaws that enable the user to "pry" into or "hook" onto cables
Maximum conductor size is 2 x 500MCM

View Product Details

List Price: $149.00

In Stock:

View Payment Options

Recommended for you

AEMC 2110.75 - AC Current Probe Model MD314

Unique hook-shaped jaws that enable the user to "pry" into or "hook" onto cables
Maximum conductor size is 2 x 500MCM

The MD314 is built for ruggedness, versatility, and ease of use. It is a general purpose 500AAC current probe. Accommodates 2 x 500MCM and bus bars. Output signal is 1mV/A. Output termination is double insulated 5 ft lead with safety banana plugs.

AEMC 2110.75 Specifications
Operating Range
Current Range	4 to 500AAC
Frequency Range	48 to 1000Hz
Common Mode Voltage	600VAC
Current Overload	700A for 10 min
Load Impedance	1mW
Reference Conditions	23°C ±3°K, 20 to 75% RH, external magnetic field <40A/m, no DC component, no external current carrying conductor, test sample centered, 1MW load
Working Voltage	600VAC
Influence of Adjacent Conductor
Range Value	50Hz
Influence of Adjacent Conductor	< 30mA/A
Influence of Conductor Position
Influence of Conductor Position	± 1.5% ± 0.1A of Reading @ 50/60Hz
Output Signal
Output Signal	1mAAC / AAC (500mV at 500AAC)
Phase
Range Value	45 to 1000Hz
Phase Shift	< 7°
Mechanical Specifications
Colors	Dark gray handles
Dimensions	2.6 x 7.68 x 1.34" (66 x 195 x 34mm)
Drop Test	1.5m (IEC 68-2-32)
Jaw Opening	1.3" (33mm)
Material	Handles: 10% Fiberglass charged polycarbonate UL 94 V0
Maximum Bus Bar Size	2.48 x 0.20" (63 x 5mm)
Maximum Cable Diameter	1.18" (30mm)
Mechanical Shock	100g (IEC 68-2-27)
Operating Temperature	-5° to 122°F (-15° to 50°C)
Output	Double insulated 5 ft (1.5 m) lead with safety banana plug
Protection Index (IP)	IP 20 (IEC 529)
Storage Temperature	-40° to 185°F (-40° to 85°C)
Vibration	Test per IEC 68-2-6
Weight	14.82 oz (420g)
External Influences
Influence of Temperature	<0.1% per 10K°
Safety Reference Specifications
Safety Ratings	EN 61010-2-32
Agency Approvals	CE Mark
