AEMC 1201.21 - AC Current Probe Model MD303 (500A, 1mA/A, Lead)

Name: AEMC 1201.21 - AC Current Probe Model MD303 (500A, 1mA/A, Lead)
Brand: AEMC Instruments
SKU: AEMC1201.21
Price: 141.55 USD
Availability: InStock

0 reviews | UPC: 068533807002 | Model: AEMC Instruments 1201.21

AEMC 1201.21 - MD303 Probe AC General Purpose

Compare

AC Current Probe Model MD303 (500A, 1mA/A, Lead)

Unique hook-shaped jaws that enable the user to "pry" into or "hook" onto cables
Maximum conductor size is 2 x 500MCM
Works as a traditional current transformer with ratio of 1000:1

View Product Details

List Price: $149.00

In Stock:

View Payment Options

Recommended for you

AEMC 1201.21 - AC Current Probe Model MD303 (500A, 1mA/A, Lead)

Unique hook-shaped jaws that enable the user to "pry" into or "hook" onto cables
Maximum conductor size is 2 x 500MCM
Works as a traditional current transformer with ratio of 1000:1

The MD303 is built for ruggedness, versatility and ease of use. It is a general purpose 500AAC current probe. Accommodates 2 x 500MCM and bus bars. Output termination is double insulated 5 ft lead with safety banana plugs.

AEMC 1201.21 Specifications
Operating Range
Current Range	4 to 500AAC
Frequency Range	48 to 1000Hz
Common Mode Voltage	600VAC
Current Overload	700A for 10 min
Load Impedance	5W max noninductive
Open Secondary Voltage	Limited to 10V Peak max
Reference Conditions	23°C ±5°K, 20 to 75% RH, external magnetic field <40A/m, no DC component, no external current carrying conductor, test sample centered, 5W load
Ratio
Ratio	1000:1
Working Voltage	600VAC
Influence of Adjacent Conductor
Range Value	50Hz
Influence of Adjacent Conductor	< 30mA/A
Influence of Conductor Position
Influence of Conductor Position	± 1.5% ±0.1A of Reading @ 50/60Hz
Output Signal
Output Signal	1mAAC / AAC
Phase
Range Value	45 to 1000Hz
Phase Shift	< 7°
Mechanical Specifications
Altitude	Operating: 0 to 2000m; Non-operating: 0 to 12km
Colors	Dark gray handles
Dimensions	2.6 x 7.68 x 1.34" (66 x 195 x 34mm)
Drop Test	1.5m (IEC 68-2-32)
Jaw Opening	1.3" (33mm)
Material	Handles: 10% Fiberglass charged polycarbonate UL 94 V0
Maximum Bus Bar Size	2.48 x 0.20" (63 x 5mm)
Maximum Cable Diameter	1.18" (30mm)
Mechanical Shock	100g (IEC 68-2-27)
Operating Temperature	-5° to 122°F (-15° to 50°C)
Output	Double insulated 5 ft (1.5m) lead with safety banana plugs
Protection Index (IP)	IP 20 (IEC 529)
Storage Temperature	-40° to 185°F (-40° to 85°C)
Vibration	Test per IEC 68-2-6
Weight	14.82 oz (420g)
External Influences
Influence of Temperature	<0.1% per 10K°
Safety Reference Specifications
Safety Ratings	EN 61010-2-32
Agency Approvals	CE Mark

Tech Specs

Test Equipment General Attributes
Product Weight	1.74 LBS
Shipping Weight	2 LBS
