AEMC 2129.6 - Hipot Tester Model H111

0 reviews | UPC: 068533821005 | Model: AEMC Instruments 2129.6


Hipot Model H111 (5kVAC w/SP02)

  • AC Hipot programmable to 5kV @ 40mA
  • DC Hipot programmable to 6kV @ 10mA (H216)
  • Continuity measurement @ 100mA
  • Insulation resistance to 9900MW @ 500VDC and 1000VDC and to 1990mW @ 50V/100V
  • ARC current detection with programmable limits
  • Programmable ramp, test and wait times, output voltages and trip limits
  • Selectable AC test frequency (50Hz or 60Hz)
  • Set trip current without loads or high voltage present
  • Automatic testing - store up to 10 tests (up to 16 steps per test)
  • Line and load regulation for linear output voltage
  • Highly visible warning light indicator for HV output
  • Pass and fail lights with adjustable buzzer
  • Program lock-out feature to prevent user error or program changes
  • PLC remote control (9 pin connector); Serial communication port (9 pins)
  • Includes tester, high voltage test pistol, return lead with retainer, US AC 110V power chord, and manual
View Product Details

List Price: $1,595.00
