AEMC 2134.17 - Sentinel Current Logger Model SDL A303

Name: AEMC 2134.17 - Sentinel Current Logger Model SDL A303
Brand: AEMC Instruments
SKU: AEMC2134.17
Price: 1182.75 USD
Availability: InStock

0 reviews | UPC: 068533814024 | Model: AEMC Instruments 2134.17

Compare

Sentinel Current Logger Model SDL A303 (AAC, 3-Channel, 1000A, DataView Software, Rechargeable NiMH batteries)

3 Channels
Current Range: 5 to 1000A
True RMS measurements
Low-cost, self contained, portable
Integral flexible current probes for three -phases
Measures up to 3000A
Stores up to 480,000 points (1MB)
64 samples per cycle
Includes DataView Software
USB Communication
600V Cat. lll

View Product Details

List Price: $1,245.00

In Stock:

View Payment Options

Recommended for you

AEMC 2134.17 Specifications
ELECTRICAL
Number of Channels	Three
Input Termination	Hard-wired flexible CTs
Current Range	5 to 1000A
Resolution	0.1A
Accuracy	±1% of Reading ± 1.5A
Sample Rate	64 samples/cycle
Storage Rate	Programmable from 250ms to 12 hours
Storage Technique	Stop when full, FIFO, and Extended Recording Mode (XRM?)
Memory Capacity	480,000 measurements (1MG)
Communication	USB 2.0 optically isolated
Controls	One button to turn logger on/off and start/stop recording
Indicators	Red, Yellow and Green status indicators
Power Source	AC power/rechargeable NiMH batteries
Battery Life*	Power ride through 10 hours
MECHANICAL
Protection Index	IP50
Dimensions	6.73 x 4.76 x 2.17" (171 x 121 x 55mm)
Case Material	Polycarbonate UL94 V-2
ENVIRONMENTAL
Operating Temperature	14° to 122°F (-10° to 50°C)
Storage Temperature	-4° to 140°F (-20° to 60°C)
Relative Humidity	0 to 85% RH
SAFETY
Safety Rating	600V Cat. III, 300V Cat. IV
Double Insulation	Yes
