AEMC 2130.30-Refurb - Like New-Open Box Model, Full Warranty Megohmmeter Model 5070

Name: AEMC 2130.30-Refurb - Like New-Open Box Model, Full Warranty Megohmmeter Model 5070
Brand: AEMC Instruments
SKU: AEMC2130.30-Refurb
Price: 3795.25 USD
Availability: InStock

0 reviews | Model: AEMC Instruments 2130.30-Refurb

Compare

Like New-Open Box Model, Full Warranty Megohmmeter Model 5070 (Graphical, Analog Bargraph, Backlight, Alarm, Timer, 500V, 1000V, 2500V, 5000V, Ramp, Auto DAR/PI/DD, RS-232 w/DataView Software) Model 5070

Like New-Open Box Model, Full Warranty
True Megohmmeter with selectable test voltage from 40 to 5100V
Insulation measurements from 30kΩ to 10TΩ
Automatic step voltage with programmable step and dwell times - three profiles can be stored, each with up to five steps
Programmable temperature compensation of resistance readings
Automatic calculation of DAR, PI and DD values
Direct measurement and display of Resistance, Test Voltage, Run Time, Capacitance and Leakage Current
Automatic test inhibition if live voltage is present
Automatic discharge and display of discharge voltage
Large graphic display with five line alphanumeric display and graph of all test results
Rugged weatherproof field case
RS-232 interface for direct printing of results
128kB memory for storing field test data
Remote operation from PC
Includes soft accessory bag, one red, one blue, one black lead with integral 5000V rated hippo clips, one jumper lead for use with guard terminal, 5ft RS-232 DB9/DB25 F/F cable, DataView Lite Software, rechargeable battery pack, US 120V power cord, and User manual

View Product Details

List Price: $3,995.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Cables - Misc

for the AEMC Instruments 2130.30-Refurb

AEMC Instruments 2119.45 Cable Replacement PC RS-232, DB9 F/F 6 ft Null Modem Cable...

Catalog: 2119.45

(0)

In Stock!

Add to Cart

AEMC 2130.30-Refurb - Like New-Open Box Model, Full Warranty Megohmmeter Model 5070

AEMC Like New-Open Box Model, Full Warranty Megohmmeter Model 5070

Like New-Open Box Model, Full Warranty
True Megohmmeter with selectable test voltage from 40 to 5100V
Insulation measurements from 30kΩ to 10TΩ
Automatic step voltage with programmable step and dwell times - three profiles can be stored, each with up to five steps
Programmable temperature compensation of resistance readings

The Megohmmeter Model 5070 is a fully automated 5000V graphical insulation tester. Selectable and programmable test voltage (40 to 5100V). Programmable temperature correction of resistance readings. The Model 5070 is the only megohmmeter to offer both a graphical plot of the test right on the instruments, as well as a digital presentation of the test results. It has a large graphic display with five lines of alphanumeric display and graph. It also offers the ability to program up to three steps voltage profiles, each containing up to five steps. The Model 5070 has an RS-232 port which provides the ability to configure the unit and run the test from a PC. Test results can be generated directly to a printer using the DataView graphing and analysis software.

AEMC 2130.30-Refurb Specifications
Measurement Range
Test Voltage/Range	500V 30kΩ to 2000GΩ (2TW) / 1000V 100kΩ to 4000GΩ (4TW) / 2500V 100kΩ to 10,000GΩ (10TΩ) / 5000V 300kΩ to 10,000GΩ (10TW)
User Selectable Test Voltage	Programmable:40 to 1000V: 10V increments; 1000 to 5100V: 100V increments - Programmable step voltage and duration in five steps. Three profiles can be stored.
Accuracy	1kΩ to 40GΩ ±5% of Reading ± 3cts / 40GΩ to 10TΩ ±15% of Reading ± 10cts
Voltage Test/Safety Check	0 to 1000V AC/DC (16 to 420Hz), 1V Resolution
Voltage Warning Indicator	Yes >25V
Test Inhibition	Yes >25V
Smooth Function (user selectable)	Digital filtering stabilizes display readings
GENERAL
Storage of Readings over Time R(t)	128kB memory
Report Print-out Direct to Printer	Preset format
Storage of Test Results	128kB memory with RS-232
PC Application Software	Yes (included)
Power Source	Eight NiMH rechargeable batteries 85 to 256V (50/60Hz)

Micro / Milli / Meg Ohmmeters/Megohmmeter / Insulation Resistance Testers Template
IR Test Voltage	1,000 V, 2,500 V, 5,000 V, 500 V
Maximum Insulation Resistance	10 T Ohms (10000 G Ohms)
Automated Test Results	Dielectric Absorption Ratio, Dielectric Discharge, Leakage Current, Step Voltage
Type	Battery, Line
Minimum Insulation Resistance	30 K Ohms (0.00003 G Ohms)
Variable Incremental Voltage	Yes
Display (Megohmmeter)	Digital, Graphical
Continuity Test	Yes
Live Circuit Voltage Detection	Yes
Power Supply	Battery, Line Powered
Timer	Yes
CAT Rating	III
CAT Voltage	1,000 V
Test Equipment General Attributes
Unique Features	Automatic step voltage with programmable step and dwell times - three profiles can be stored, each with up to five steps Programmable temperature compensation of resistance readings Automatic calculation of DAR, PI and DD values Direct measurement and display of Resistance, Test Voltage, Run Time, Capacitance and Leakage Current Automatic test inhibition if live voltage is present Automatic discharge and display of discharge voltage Large graphic display with five line alphanumeric display and graph of all test results
Warranty	1 YEARS
Interfaces I/O	RS-232
IP Rating	IP53
Product Weight	9.5 LBS
Product Height	7.09 IN
Product Length	10.63 IN
Product Width	9.84 IN
Shipping Weight	20.00 LBS
Data Logging	Yes
ECCN Number	EAR99
Calibration Included	None
Battery Type	Ni-Cad
Power Supply Voltage	120V/220V Universal, Battery Powered
Country of Origin	France
