AEMC 1208.56 - Clamp-On Power Meter Model F23

Name: AEMC 1208.56 - Clamp-On Power Meter Model F23
Brand: AEMC Instruments
SKU: AEMC1208.56
Price: 850.25 USD
Availability: InStock

0 reviews | Model: AEMC Instruments 1208.56

Compare

Clamp-On Power Meter Model F23 (TRMS, 1000AAC/DC, 600VAC/DC, 600kW, Frequency)

True RMS
Current 1000Amp and 1500Amp pk.
Voltage 600Volt and 1500Volt pk.
Power 600kW, VA or VAR.
Power factors and power shift.
Measurement of total harmonic distortion.
Large backlit display with three reading levels (3 x 10,000cts).
En 61010-2-032, 600V CAT. III

View Product Details

List Price: $895.00

In Stock:

View Payment Options

Recommended for you

AEMC 1208.56 - Clamp-On Power Meter Model F23

True RMS
Current 1000Amp and 1500Amp pk.
Voltage 600Volt and 1500Volt pk.
Power 600kW, VA or VAR.
Power factors and power shift.
Measurement of total harmonic distortion.
Large backlit display with three reading levels (3 x 10,000cts).
En 61010-2-032, 600V CAT. III

AEMC 1208.56 Specifications
General
Current	300mA to 1000A AC (1500A pk)
Voltage	50mV to 600V AC (1500V pk)
Peak Value	PEAK ±2ms
Crest Factor	1 to 10
Frequency	0.5Hz to 20kHz
Power	Active: 10W 600kW - AC / Reactive: 10VAR 600kVAR - AC / Apparent: 10VA 600kA - AC
Power Factor	0 to 1
Displacement Power Factor	-1 to +1
Total Harmonic Distortion	0.2 to 600%
Distortion Factor	0.2 to 100%
Record	Min, Max and Average value
Smoothed Value	Over 3s
Display Hold	Available for every function
Monitoring Scan Mode	Programmable rate 1 to 60 min
Jaw Opening	1.7" (43mm)
Cable	1.97" (50mm)
Conductor Size	1 Busbar 3.15" x 0.20" (80mm x 5mm) / 2 Busbars 1.97" x 0.20" (50mm x 5mm)
